The quality and performance equal to original elements.
2.Temperature Range -4°F~212°F
3.Seals: nitrile seals, fluorocarbon seals for corrosive fluids.
4.Collapse pressure rating 21bar-210bar (suction Liquid Filtration)
5.Filtering filter element 3, 5, 10,20 and 50 micron.
6.Filter Medium: glass fiber, filter paper, stainless steel sinter fiber and stainless wire mesh.
7.Fluid Compatibility Compatible with all petroleum oils,water glycols, oil/water emulsions, high water base fluids,and synthetic fluids compatible with Fluoro Rubber or EPR seals
Model | Flow Nm3/min | Filtration Accuracy | Residual Oil |
015* | 1.2 | PF grade :25 μm | 5 ppm |
020* | 1-8 | AO grade :1 μm | 1 ppm |
025* | 3.6 | AA grade :0.01 μm | 0.01 ppm |
030* | 6.6 | AX grade0.01 μm | 0.001ppm |
035* | 9.6 | ACS grade:0.01 μm | 0.001 ppm |
040* | 13.2 | AR grade :1μm | / |
045* | 19.8 | AAR grade :0.01 μm | / |
050* | 25.9 | ||
055* | 37.3 | ||
060* | 19.8 |
